Horizontal Drilling Machine Construction
The drill pipe is made of special high-strength alloy steel and undergoes precision machining. It has a stable connection, is convenient to load and unload, and the internal mud circulation channel ensures the smooth progress of drilling. The guiding system integrates satellite positioning and gyroscope technologies, which can accurately monitor the parameters of the drill bit in real time. Operators can precisely adjust and control according to these parameters to ensure that the drill bit can penetrate along the predetermined trajectory.During construction, it has strong adaptability and high efficiency, and performs excellently in scenarios such as urban streets and crossing obstacles. It is easy to operate and highly intelligent, reducing the construction risks. The safety protection is comprehensive, including devices such as protective fences, emergency brakes, and leakage protection devices. It also has a fault diagnosis and early warning function. With its many advantages, the Dana Horizontal Drilling Machine has been widely praised in trenchless engineering and contributes to urban construction. EMAC will keep updating products introduction page of different emission standard version engines, welcome to subscribe our website to get latest update information.
General Specifications of Horizontal Drilling Machine Series
| Gross Weight: | N/A |
| Max.Push and Pull Force: | 480 kN |
| Max.Slewing Torque: | 23500 N.m |
| Engine Power: | 194-392 kW |
| Engine Torque: | N/A |
| Slewing Gearbox: | Max.Output Torque 15000-35000 N.m |
| Slewing Motor: | Motor Displacement 107 |
| Lead Time: | 15 – 30 Working Days |
| Payment Terms: | T/T,L/C |
| Push and Pull Gearbox: | Max.Output Torque 10000-200000 N.m |
- Dana Horizontal Drilling Machine Construction Chart
- Dana Horizontal Drilling Machine Construction Catalogue
| 194Kw | ||||||||
| 250Kw | ||||||||
| 392Kw | ||||||||
Engine Power: /Kw | 0 | 60 | 120 | 180 | 240 | 300 | 360 | 420 |
Engine Model | Engine Power | Engine Torque | Engine Model | Engine Power | Engine Torque | ||
| 450 Horizontal Drilling Machine | 194 kW | N/A | 680 Horizontal Drilling Machine | 250 kW | N/A | ||
| 880 Horizontal Drilling Machine | 392 kW | N/A | |||||
| ——END—— | |||||||
DANA Horizontal Drilling Machine Series Construction
This is the list of all series of Dana Horizontal Drilling Machine Series Construction
Click here to find automotive engines by type (Fuel System & Emission Standard).
Dana Parts for 880 Horizontal Drilling Machine
Machine Model: 880 Horizontal Drilling Machine
Engine Power: 392 Kw
Max.Push and Pull Force: 880 kN
Max.Slewing Torque: 50000 N.m
Manifold : 130-250 L/min
Dana Parts for 450 Horizontal Drilling Machine
Machine Model: 450 Horizontal Drilling Machine
Engine Power: 194 Kw
Max.Push and Pull Force: 480 kN
Max.Slewing Torque: 23500 N.m
Manifold : 130-250 L/min
Dana Parts for 680 Horizontal Drilling Machine
Machine Model: 680 Horizontal Drilling Machine
Engine Power: 250 Kw
Max.Push and Pull Force: 680 kN
Max.Slewing Torque: 27000 N.m
Manifold : 130-250 L/min
