Concrete Mixer Underground Mining

The Dana Concrete Mixer is a top – notch assistant in underground mine construction, engineered for harsh, complex conditions.Its compact and sturdy body, crafted from high – strength special steel, withstands collisions, scratches, and falling rocks, ensuring safe operation. Thoughtfully sized, it has a good loading capacity and can move nimbly in narrow mine roadways.
The mixing system is a standout feature. The drum’s uniquely designed spiral blades, with optimized angles and shapes, rotate steadily to thoroughly mix concrete, preventing segregation even on bumpy routes.
The power system is equally impressive. Equipped with a high – performance engine optimized for low – oxygen underground settings, it offers strong torque for complex terrains. Paired with Dana’s hydraulic torque converter and multi – speed gearbox, it delivers smooth, precisely controlled power.
Safety is prioritized. The full – hydraulic braking system with multi – disc wet brakes stops the vehicle effectively, and the anti – skid differential adjusts wheel torque on slippery surfaces. The high – strength cockpit protects the driver. In underground projects, from roadway lining to infrastructure building, it accurately transports and unloads materials, guaranteeing construction progress and quality, and is highly regarded by mining companies. EMAC will keep updating products introduction page of different emission standard version engines, welcome to subscribe our website to get latest update information.
If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at Drill Rig.

coming soon

General Specifications of Concrete Mixer Series

Gross Weight:	21 t
Max.Speed:	20 kph
Max.Grade:	25 %
Engine Power:	120 kW
Engine Torque:	618 Nm
Front Axle Model:	Dana 123-xxx
Rear Axle Model:	Dana 123-xxx
Lead Time:	15 – 30 Working Days
Payment Terms:	T/T,L/C
Transmission Drop:	LD


Concrete Mixer	120Kw
Engine Power: /Kw	0	30	60	90	120	150	180	210

Concrete Mixer

120Kw

Engine Power:

/Kw

120

150

180

210

Dana Concrete Mixer Underground Mining Catalogue
Engine Model	Engine Power	Engine Torque	Engine Model	Engine Power	Engine Torque
Concrete Mixer	120 kW	618 Nm

——END——



DANA Concrete Mixer Series Underground Mining

This is the list of all series of Dana Concrete Mixer Series Underground Mining
