Small Personal Carrier Underground Mining

In underground mine operations, the Dana Small Personal Carrier is a crucial piece of equipment for ensuring the commuting of personnel.
It has a compact body with a frame made of high-strength steel, which is sturdy and allows it to flexibly navigate through narrow mine roadways, being fearless of collisions, scratches, and the impact of falling rocks. The power system is outstanding. It is equipped with engines from well-known brands, such as the Deutz turbocharged engine. Optimized for the low-oxygen environment underground, it works in conjunction with Dana’s self-developed gearbox and hydraulic torque converter, providing strong power, stable transmission, and energy efficiency.The interior space is reasonably arranged. The number of seats ranges from 6 to 18 and can be customized according to actual needs. The seats are designed ergonomically, ensuring a comfortable ride, and there is also sufficient space for movement. The safety performance is remarkable. It adopts a gas-liquid hybrid braking system, and the multi-disc wet brakes have been treated for water and dust resistance. The anti-skid differential can adapt to complex road surfaces. The cockpit is equipped with a safety warning and monitoring system, and the body is made of fireproof and flame-retardant materials.
In practical applications, it can not only meet the daily transportation needs of personnel but also play a role in emergency evacuations, ensuring the safety of mine production and personnel. It is highly favored by mining enterprises and is an excellent choice for transporting personnel underground. EMAC will keep updating products introduction page of different emission standard version engines, welcome to subscribe our website to get latest update information.
If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at Drill Rig.

coming soon

General Specifications of Small Personal Carrier Series

Gross Weight:	8.4 t
Max.Speed:	40 kph
Max.Grade:	30 %
Engine Power:	66 kW
Engine Torque:	353 Nm
Front Axle Model:	Dana 211-xxx
Rear Axle Model:	Dana 111-xxx
Lead Time:	15 – 30 Working Days
Payment Terms:	T/T,L/C
Transmission Drop:	LD


Small Personal Carrier	66Kw
Engine Power: /Kw	0	30	60	90	120	150	180	210

Small Personal Carrier

66Kw

Engine Power:

/Kw

120

150

180

210

Dana Small Personal Carrier Underground Mining Catalogue
Engine Model	Engine Power	Engine Torque	Engine Model	Engine Power	Engine Torque
Small Personal Carrier	66 kW	335 Nm

——END——



DANA Small Personal Carrier Series Underground Mining

This is the list of all series of Dana Small Personal Carrier Series Underground Mining
