Load Haul Dumper Underground Mining

The Dana Load Haul Dumper excels in construction machinery with its powerful performance. Its core power system, featuring a Dana-developed hydraulic torque converter and power shift transmission, combined with a high-efficiency motor or engine, ensures smooth operation and strong, continuous power for heavy-duty scraping and transporting tasks, significantly boosting efficiency.
The Dana 53R axle, with a torque output of 300,000 Nm and load capacities of up to 80 tons, offers customizable options like various gear ratios, differential types, flanges, axle widths, and installation methods, making it adaptable to diverse working conditions.
Equipped with a full-hydraulic dual-circuit braking system and NO-SPIN anti-slip differentials, the machine ensures safe braking even in harsh environments. Some models also feature an active safety braking system for added safety.
In practice, the Dana Load Haul Dumper’s flexibility and power make it ideal for underground mining and complex construction projects like railways, highways, and tunnels, where it efficiently handles material transport tasks. EMAC will keep updating products introduction page of different emission standard version engines, welcome to subscribe our website to get latest update information.
If you are in need of engine model that not available on our website for the moment, please contact EMAC sales team for technical details and related documents, our well trained sales and engineering team will help you with all products and techical documents available here at Drill Rig.

coming soon

General Specifications of Load Haul Dumper Series

Gross Weight:	12.5-58.5 t
Max.Speed:	20 kph
Max.Grade:	30 %
Engine Power:	55-368 kW
Engine Torque:	255-2324 Nm
Front Axle Model:	Dana 14D2149-xxx，53R300-xxx
Rear Axle Model:	14D2149-xxx，53R300-xxx
Lead Time:	15 – 30 Working Days
Payment Terms:	T/T,L/C
Transmission Drop:	LD

1.5 m³ LHD	55Kw
2m³ LHD	65Kw
3 m³ LHD	130Kw
4 m³ LHD	170Kw
6 m³ LHD	260Kw
8 m³ LHD	368Kw
Engine Power: /Kw	0	55	110	165	220	275	330	385

Dana Load Haul Dumper Underground Mining Catalogue
Engine Model	Engine Power	Engine Torque	Engine Model	Engine Power	Engine Torque
1.5 m³ LHD	55 kW	255 Nm	2 m³ LHD	65 kW	300 Nm
3 m³ LHD	130 kW	650 Nm	4 m³ LHD	170 kW	1080 Nm
6 m³ LHD	260 kW	1650 Nm	8 m³ LHD	368 kW	2324 Nm
