Dana Parts for 3Boom Drill Rig
3Boom Drill Rig is a rock drilling rig carefully built by Dongfeng Dana. This model has a total weight of 48 tons and a maximum speed of 10 kph. The power of 173 kW and the engine of 907 Nm meet the needs of various working conditions and have excellent power and speed performance. Dana’s well-known model Dana 37RL118-xxx is selected as the front axle and Dana 213-xxx is used as the rear axle. The transmission is accurate and reliable, and the braking system is safe and efficient.
3Boom Drill Rig provides reliable protection for your drilling operations with excellent performance and high-quality Dana components.
As part of EMAC, DANA provides non-power transmission and drive solutions for thermal management systems, control systems, transmissions and hydraulic accessories. We also provide components such as winches,pimp drives , piston motors and pumps.
We provide full life cycle services for all customers, from design to power system supply, from installation to commissioning, from after-sales service training to spare parts supply, from trouble shooting to overhaul technical support.
EMAC Group Participates in Automechanika Istanbul Exhibition in Istanbul
EMAC Group, provide a one-stop service with a complete power chain for Automotive, has announced its participation in the Automechanika Istanbul Exhibition in Istanbul, Turkey. The exhibition will take place from June 8th to June 11th, 2023.
As one of the largest automotive events in the world, the Automechanika Istanbul Show attracts exhibitors and visitors from across the globe. Our Company is excited to showcase its latest products and services at the event, which will provide an excellent opportunity to network with industry professionals and connect with potential customers.
As one of the largest automotive events in the world, the Automechanika Istanbul Show attracts exhibitors and visitors from across the globe. Our Company is excited to showcase its latest products and services at the event, which will provide an excellent opportunity to network with industry professionals and connect with potential customers.
EMAC Customer Interview-Thailand Engineering Company
EMAC’s customer interview video of 2023, EMAC finished a series of customer interview with 10 different business partners from different countries and regions, most of videos are took at customer’s company and factory, collecting all reviews and evaluations of EMAC, covering different industries in different country and regions, we believe this series of EMAC customer interview videos can help all of other customers get to know more about EMAC, our true customer interview case can greatly help customers relieve their worries, and build their confidence to cooperate with EMAC.
A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust !
A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust !
EMAC Customer Interview-Indonesia Shipyard
EMAC’s customer interview video of 2023, EMAC finished a series of customer interview with 10 different business partners from different countries and regions, most of videos are took at customer’s company and factory, collecting all reviews and evaluations of EMAC, covering different industries in different country and regions, we believe this series of EMAC customer interview videos can help all of other customers get to know more about EMAC, our true customer interview case can greatly help customers relieve their worries, and build their confidence to cooperate with EMAC.
A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust!
A Promise is A Promise, EMAC always do what we say, and for customer’s feedback, also 100% original from clients’s real words. EMAC, a Chinese company that you can trust!
Identification and Classification Report for Air Transport of Goods
Sinomac is dedicated to providing customers with safe, reliable cargo transportation services. Whether by sea or by air, ensuring safe delivery of our clients’ goods is at the heart of our operations. However, due to the complex nature of some cargo, especially industrial equipment like engines, many clients have concerns about whether such items might be classified as dangerous goods in air transport. To address these concerns, Sinomac provides a detailed analysis from multiple perspectives, including engine structure, relevant regulations, and the evaluations of authoritative inspection bodies, to give clients a clear and professional answer to this question.
Advantages of 3Boom Drill Rig
Precise control：Equipped with an advanced hydraulic control system, the 3boom drill rig offers unparalleled precision.
Economic stability: Higher payload capacity,excellent fuel effciency,Wide distance between supporting point of the dump body, the truck is reliable.
Long service Life: low maintenance cost and long lifetime, dual axles + swing axle design, the rig is more powerful, each tire’s load is evenly and lifetime is longer.
Powerful: Using Dana Brevini Orbital motor, large displacement, more efficient
Technical Specifications
General Information
Drill Rig Model | Max.Speed | Gross Weight | Engine Power | Engine Torque |
| 1Boom Drill Rig | 10 kph | 12.5 t | 58 kw | 258 Nm |
| 2Boom Drill Rig | 10 kph | 25 t | 120 kw | 618 Nm |
| 3Boom Drill Rig | 10 kph | 48 t | 173 kw | 907 Nm |
Transmission
Technical Indicator | Parameter | Model |
| Drop | LD | Dana R32000 – xxx |
| Input Flange Type | 5C | Dana R32000 – xxx |
| Output Flange Type | DIN180 | Dana R32000 – xxx |
| Control Valve Type | 24V | Dana R32000 – xxx |
| Modulation | Yes | Dana R32000 – xxx |
| Inching | No | Dana R32000 – xxx |
| Parking Brake | No | Dana R32000 – xxx |
| ——END—— | ||
Front Axle
Technical Indicator | Parameter | Model |
| Bevel Set Ratio | 3.727 | Dana 37RL118 – xxx (Wuxi Bevnt) |
| Ring Gear Position | LHS (Looking from Input Flange Side) | Dana 37RL118 – xxx (Wuxi Rinnt) |
| Planet Gear Ratio | 6 | Dana 37RL118 – xxx (Wuxi Plant) |
| Wheel Hub Bolt | BCD 425mm, 12 studs M22×1.5, L = 77mm | Dana 37RL118 – xxx (Wuxi Whent) |
| Differential Type | Hydraulic | Dana 37RL118 – xxx (Wuxi Difnt) |
| Service Brake | 3 Plate LCB | Dana 37RL118 – xxx (Wuxi Sernt) |
| Parking Brake | Disc | Dana 37RL118 – xxx (Wuxi Parnt) |
| Input Flange Type | DIN180 | Dana 37RL118 – xxx (Wuxi Inpnt) |
| Mount Type | Pad | Dana 37RL118 – xxx (Wuxi Mount) |
| Flange to Flange Distance | 2310mm | Dana 37RL118 – xxx (Wuxi Flant) |
| ——END—— | ||
Rear Axle
Technical Indicator | Parameter | Model |
| Bevel Set Ratio | 33/9 | Dana 213 – xxx |
| Ring Gear Position | LHS (Looking from Input Flange Side) | Dana 213 – xxx |
| Planet Gear Ratio | 6 | Dana 213 – xxx |
| Wheel Hub Bolt | BCD 335mm, 10 studs M22×1.5, L = 76mm | Dana 213 – xxx |
| Differential Type | Standard | Dana 213 – xxx |
| Service Brake | N266, 80 bar max. | Dana 213 – xxx |
| Parking Brake | N/A | Dana 213 – xxx |
| Input Flange Type | DIN150 | Dana 213 – xxx |
| ——END—— | ||
Drill Rotation/ Pushpull Control
Technical Indicator | Parameter | Model |
| Displacement | 80 – 393cc/r | Dana Brevini Orbital motor |
| Rating Pressure | 210bar | Dana Brevini Orbital motor |
| ——END—— | ||
Cylinder Oil control
Technical Indicator | Parameter | Model |
| Flow | 80 – 120L/min | Dana Brevini HPV4/177 |
| Rating Pressure | 350bar | Dana Brevini proportional valve HPV4/177 |
| ——END—— | ||
Hydraulic Control Group
Technical Indicator | Parameter | Model |
| Flow | 60 – 140L/min | Dana Brevini AR/NO |
| Rating Pressure | 350bar | Dana Brevini AR/NO industry valve and cartridge |
| ——END—— | ||
FAQ
Note: All Above Data are Just for Reference, All Data Might Change Without Notices or Updates, Please Contact Our Sales Team to Confirm All Details Via WhatsApp or Email.
